Electric Carbon Film Heating 130W/m² for Wood Floors
Ecofilm is an ultra-thin 130W/m² electric heating element for approved floating engineered wood, laminate and carpet constructions.
Measure the clear floor area and round down - we size the elements before dispatch, and they must not be shortened, folded or overlapped on site.
Online checkout is coming back shortly. In the meantime we take orders by phone or order form - usually quicker, because we can sanity-check the size against your room first.
Overview
Ecofilm is an ultra-thin 130W/m² electric heating element for approved floating engineered wood, laminate and carpet constructions. It is installed as a dry system above the specified insulation and below a protective PET vapour barrier.
Kit includes
- Ecofilm Carbon heating roll, size as specified
- Cold cable connectors, amount to suit
- Full installation instructions
- Free technical support line 0800 756 6862
- Free next day delivery!
Ecofilm, is rated at 130W/m2 Just select the nearest size you require to provide maximum floor coverage, and Carbon Heat will tailor the product to your room dimensions. The Ecofilm system is NOT suitable for installation in a bathroom, this is because its not an earthed product.
Before choosing a size
Measure only the clear floor area, excluding fixed units, baths, shower trays and other permanently covered areas. Send us the room plan and we will select the element widths and lengths. Do not shorten, fold or overlap the supplied elements.
Installation limits
This Ecofilm product is not earthed and must not be installed in a bathroom or another wet area. The final connection, thermostat and testing must be completed by a qualified electrician in accordance with the installation instructions and applicable wiring regulations.
Delivery and guarantee
Free next-day delivery to mainland UK on complete heating systems, with no minimum order. Accessories ordered on their own may be sent by standard delivery - ask us before ordering if the date matters.
This system carries a 10 year guarantee, subject to the manufacturer's installation terms. It covers the heating element itself rather than damage caused during fitting, so keep your installation record.
Not sure it is right for your floor? Call 0800 756 6862 before you order.
Why Choose Us?
What every order includes
Free next-day delivery
On every underfloor heating system, anywhere in mainland UK.
Ten year guarantee
Every carbon film system carries a 10 year guarantee.
Free technical support
Talk to an installer before you buy, and while you fit it.
Sized to your room
Tell us your dimensions and we will size the system for you.
